Giới thiệu BỘ CẦN SIẾT CÓ LẪY GẠT ĐẢO CHIỀU VÀ ĐẦU SOCKET 3/8 INCH WERA 634120 29 CHI TIẾT 05004048001

Version:

Unique electro-mechanical wrench, which combines both the ″displaying” and “triggering” functions in a single device.
When the set torque is reached the wrench triggers, with acoustic and tactile signals like a conventional mechanical torque wrench.
In addition the value achieved is displayed and can be transferred to a PC.
The additional ″displaying” mode provides a continuous visual indication to the user of the torque that is being applied.
Saves and documents up to 7500 screw tightening events.
An automatic key lock prevents accidental changes to the settings.
A PIN code can be entered to prevent unauthorised changes to the settings.
The wrench offers a very wide measurement range.
Integrated automatic reminder of calibration after the number of operations and elapsed time.

Units of measure:

Nm, lbfft, lbfin.

Easy input of pitch settings:

For plug-in heads with a different reference dimension, simply input the new dimension.
No laborious calculations with formulae.

QuickRelease:

Secure engagement and quick change of plug-in heads.
Robust, compact body.
Tolerance limit settings,shown clearly on a display with colour changes.
Very simple operation; complete use and menu selection with just 4 buttons.
2-component handle, resistant to oils, greases, fuels, brake fluids, and Skydrol.
USB interface for exporting the data.
With reversible plug-in ratchet.

Standard:

Tested to DIN EN ISO 6789.

Supplied with:

Sturdy plastic box (sizes 100 and 200) and sturdy metal box (from size 400) with 2 batteries (1.
5 V mignon / AA / LR6).

Optional extras:

USB adapter, cable with latching plug, SENSOMASTER 4 software.

Note:

The guaranteed measuring accuracy of the torque is achieved only once the torque range has been calibrated to DIN EN ISO 6789.
-----------


maximum torque

200 Nm



Direction of tightening

For right- and left-hand tightening



Torque measuring accuracy

±2 %



Exchangeable tool

Plug-in head



Interface

USB interface



Test certificate

Manufacturer’s test certificate



Calibration

O1



Series

MANOSKOP 730DR



Overall length L

594 mm



Torque range

20 Nm - 200 Nm



Torque range

15 lbfft - 150 lbfft



Torque range

180 lbfin - 1,800 lbfin



Adjustment resolution

0.5 Nm



Display resolution

0.1 Nm



Weight

1,663 g



Adjusted reference dimension on the torque wrench [l₂]

25 mm



Square drive

1/2 inch



Socket for plug-in head

14×18 mm



Display

digital



Release signalling

optisk; akustisk; haptisk



Trigger principle

mechanical short-travel release



Power supply

Battery-powered



Number of batteries contained

2



Battery type

Mignon, AA



Article no of the battery / rechargeable battery fitted

081561 LR6



Connection format

for plug-in heads (rectangular socket)



Measurement technology

electronic



Quick release/ quick-change function

yes



Data can be recorded

yes



Setting the trigger value

digital, adjustable



Feedback

visning; udløsning; acoustic signal



Reversible reading

Nm; lbfin; lbfft



Measurement process

Torque



Adjustable trigger value

adjustable



Standard

DIN EN ISO 6789



Lever length without plug-in head [l₁]

515 mm



Lever length including factory calibration reference dimension [l₃]

540 mm



Type of product

Torque Wrench
